结构特征characteristic：
1、 采用内筒体加外包，中间填充保温材料结构。The inter barrel with outsourcing, insulation layer is filled heat preservation material structure.
2、 材料为卫生级不锈钢。Materials is sanitation stainless steel
3、 结构设计极具人性化，可操作性强。Structure design is extremely humanization, the maneuverability is strong
4、 筒体内壁过渡段采用圆弧过渡，保证卫生无死角。The barrel body wall using arc transition section, sanitation without blind Angle
罐体配置Tanks Configuration：
1、 快开式人孔Quick open manhole
2、 各种外形的CIP清洗器Various shape CIP cleaner
3、 防蝇虫卫生级透气罩Prevent fly worm sanitation air masks
4、 可调式三角支脚Adjustable triangle feet
5、 可拆卸进料管套件Removable feeding inlet tube suite
6、 温度计（根据客户要求配置）The thermometer (according to the customer request configuration)
7、 爬梯（根据客户要求配置）The ladder (according to the customer request configuration)
8、 推进式侧搅拌。Push type side blending
9、 液位计及液位控制（根据客户要求配置）Level-meter and level control (according to the customer request configuration)
10、 防涡板Prevent eddy plate
技术参数Technical Parameter：
|
有效容积
Volume
|
筒体尺寸(D×H)
Barrel Size
|
总高(H)
Total height
|
进出料口径
Inlet & Outlet Diameter
|
保温层
Heat
Preservation
layer
|
电机功率
Motor Power
|
搅拌速度
Blending Speed
|
|
（L）
|
(mm)
|
(mm)
|
(mm)
|
(mm)
|
(kw)
|
(r/min)
|
|
1000
|
1060×1220
|
2550
|
51
|
60
|
0.75
|
960
|
|
1500
|
1160×1500
|
2850
|
51
|
60
|
1.1
|
960
|
|
2000
|
1340×1500
|
2900
|
51
|
60
|
1.1
|
960
|
|
3000
|
1410×2000
|
3400
|
51
|
60
|
1.5
|
960
|
|
4000
|
1620×2000
|
3450
|
51
|
60
|
1.5
|
960
|
|
5000
|
1810×2000
|
3500
|
51
|
60
|
2.2
|
960
|
|
6000
|
1980×2000
|
3550
|
51
|
60
|
2.2
|
960
|
|
7000
|
1930×2440
|
4000
|
51
|
60
|
3
|
960
|
|
8000
|
2060×2440
|
4000
|
51
|
60
|
3
|
960
|
|
9000
|
2180×2440
|
4050
|
51
|
60
|
3
|
960
|
|
10000
|
2300×2440
|
4050
|
51
|
60
|
3
|
960
|
|
12000
|
2270×3000
|
4600
|
51
|
60
|
4
|
960
|
|
15000
|
2530×3000
|
4700
|
51
|
60
|
4
|
960
|
|
20000
|
2640×3660
|
5400
|
51
|
60
|
5.5
|
960
|
如客户提出特殊要求可根据用户要求定作。总高（H）是根据出料口高度800mm而得出的数据，如改变出料口高度，总高（H）作相应调整。
If customer has special requirement that can be set according to the requirements of users. Total height (H) is according to the mouth of highly 800mm data, such as changing mouth height, total height (H) adjusted accordingly.
