可作储液罐、混料罐、暂存罐、储水罐等。适用于食品、乳制品、果汁饮料、医药化工及生物工程等领域。
It is can used as storage tank, blending tank, registing tank, water storage tank and so on. Apply to food, dairy, juice, beverage, medicine, chemical and biological engineering, etc
结构特征characteristic：
1、 采用单层不锈钢结构。The single stainless steel structure
2、 材料为卫生级不锈钢。Materials is sanitation stainless steel
3、 结构设计极具人性化，可操作性强。Structure design is extremely humanization, the maneuverability is strong
4、 筒体内壁过渡段采用圆弧过渡，保证卫生无死角。The barrel body wall using arc transition section, sanitation without blind Angle
罐体配置Tanks Configuration：
1、 快开式人孔Quick open manhole
2、 各种外形的CIP清洗器Various shape CIP cleaner
3、 防蝇虫卫生级透气罩Prevent fly worm sanitation air masks
4、 可调式三角支脚Adjustable triangle feet
5、 可拆卸进料管套件Removable feeding inlet tube suite
6、 温度计（根据客户要求配置）The thermometer (according to the customer request configuration)
7、 爬梯（根据客户要求配置）The ladder (according to the customer request configuration)
8、 桨式搅拌器Paddle type mixer
9、 液位计及液位控制（根据客户要求配置）Level-meter and level control (according to the customer request configuration)
10、 防涡板Prevent eddy plate
技术参数Technical Parameter：
|
有效容积
Volume
|
筒体尺寸(D×H)
Barrel Size
|
总高(H)
Total height
|
进出料口径
Inlet & Outlet Diameter
|
电机功率
Motor Power
|
搅拌速度
Mixing Speed
|
|
（L）
|
(mm)
|
(mm)
|
(mm)
|
(KW)
|
(r/min)
|
|
500
|
840×1000
|
2750
|
38
|
0.55
|
常用转速35、43、60
也可选用无级变速减速机或者双速减速机
Common speed is 35, 43, 60, Also can choose stepless speed reducer or double speed reducer
|
|
600
|
920×1000
|
2850
|
38
|
0.55
|
|
700
|
990×1000
|
2850
|
38
|
0.55
|
|
800
|
950×1220
|
3000
|
38
|
0.55
|
|
900
|
1010×1220
|
3000
|
38
|
0.55
|
|
1000
|
1060×1220
|
3150
|
51
|
0.75
|
|
1500
|
1160×1500
|
3350
|
51
|
0.75
|
|
2000
|
1340×1500
|
3410
|
51
|
1.1
|
|
3000
|
1410×2000
|
4000
|
51
|
1.5
|
|
4000
|
1620×2000
|
4250
|
51
|
1.5
|
|
5000
|
1810×2000
|
4300
|
51
|
2.2
|
|
6000
|
1980×2000
|
4550
|
51
|
2.2
|
|
7000
|
1930×2440
|
5000
|
51
|
2.2
|
|
8000
|
2060×2440
|
5000
|
51
|
3
|
|
9000
|
2180×2440
|
5050
|
51
|
3
|
|
10000
|
2300×2440
|
5050
|
51
|
3
|
|
12000
|
2270×3000
|
5600
|
51
|
4
|
|
15000
|
2530×3000
|
5700
|
51
|
4
|
|
20000
|
2640×3660
|
6400
|
51
|
5.5
|
如客户提出特殊要求可根据用户要求定作。总高（H）是根据出料口高度800mm而得出的数据，如改变出料口高度，总高（H）作相应调整。
If customer has special requirement that can be set according to the requirements of users. Total height (H) is according to the mouth of highly 800mm data, such as changing mouth height, total height (H) adjusted accordingly.
